KEI Banfire-HFFR
Brand : KEI
Sold By : Nimish
Delivery
Product Information
| # | Attribute | Value |
|---|---|---|
| 1. | brand | KEI |
KEI Banfire is processed using a Halogen Free Flame Retardant compound (HFFR). The insulation is of superior quality, 100% PVC free and eco-friendly. In case of a fire situation, Banfire does not emit toxic or poisonous fumes, which enables safe evacuation. These wires are best suited for wiring in hospitals, hotels, business establishments and high rise buildings where fire can be determined. So, give yourself the promise of security and supreme quality. Get KEI house wires and safeguard your home for life.
Nominal Cross Sectional Area of Conductor(SQ. MM) | Number/Nominal Dia of Wires [Nom.] | Thickness of Insulation [Nom.] (mm) | Overall Diameter Max. (mm) | Current Rating (Clipped Direct/Cable Tray) | Current Rating (Conduit/Trunking) | D.C Resistance [Max.] at 20°C (Ohm/km) |
|---|---|---|---|---|---|---|
| 0.75 | 24/0.2 | 0.6 | 2.8 | 7 | 8 | 26.0 |
| 1.00 | 32/0.2 | 0.6 | 3.0 | 12 | 13 | 19.5 |
| 1.50 | 30/0.25 | 0.6 | 3.4 | 14 | 17 | 13.3 |
| 2.50 | 50/0.25 | 0.7 | 4.1 | 19 | 23 | 7.98 |
| 4.00 | 56/0.3 | 0.8 | 4.8 | 25 | 31 | 4.95 |
| 6.00 | 84/0.3 | 0.8 | 5.3 | 33 | 39 | 3.30 |
*The number & diameter of conductor strands are for reference only and governed by conductor resistance.
*The above data is indicative only and may be revised without prior information. KEI will not be responsible for any damages arising out of incorrect application of its product.
